Pulsonic Bin Activators

Overview

Pulsonic Bin Activators break up compacted, arched, and bridged materials in bins, hoppers, and other mass flow devices. Unlike vibratory activators, they use acoustic energy to restore material flow, protecting equipment from damage caused by severe vibration.

HOW IT WORKS

Pulsonic systems consist of a single programmer and one or more injectors:

• Injector(s): A compressed air reservoir with a solenoid operated release valve
• Programmer: Controls the pattern of multiple instantaneous air bursts from the injectors

The system introduces multiple instantaneous sonic air bursts directly into compacted material to instantly restore flow without using shock and vibration methods that often damage hoppers.

FEATURES

• Simplicity of design and solid state reliability: Low energy consumption, low initial and installation costs, and little, if any, maintenance.
• Instantly clears bins, hoppers, and other mass flow devices of compacted solids.
• Removes disruptive materials from channels, ducts, and recesses without using shock and vibration methods that can damage equipment.
• Effectively breaks up arching, bridging, clinging, and other flow problems, restoring free flow—even with the most difficult materials.

GUARANTEE

Pulsonic Bin Activators are fully guaranteed. Your system must perform to your complete satisfaction or it may be returned for full credit.

Models

VAC-U-MAX PULSONIC BIN ACTIVATORS

P1010

• 1/4″ injector with High Pressure Air Tank
• For vessels 2 feet in diameter or smaller

P3010

• 3/4″ injector with High Pressure Air Tank
• For vessels 2-4 feet in diameter

P4040

• 1 1/2″ injector with High Pressure Air Tank
• Used in bins larger then 6 feet
